Magnaflow
Mufflers
Stainless Steel shell, Straight through flow, SS mesh wrap
around perforated core, Ceramic sound absorption packing.
Below are the Magnaflow
mufflers
that we stock. If you need something different check out
Magnaflow's website and
e-mail us a part number. We'll get you the best price. We can get most
any Magnaflow muffler in a few days and with extrtemely
competitive prices. If you find any Magnaflow parts for less,
give us an opportunity to beat them. |
 |
Dia
|
Body
Length |
Body Dia |
Pipe Alignment |
Use |
Part Number |
Price |
| 2.5" |
18" |
5" x 8" |
Offset/Center |
2.5" Eclipse Rear |
MAG-12256 |
$74 |
| 3" |
18" |
5" x 8" |
Offset/Center |
3" Eclipse Rear |
MAG-12259 |
$90 |
Resonators
|
Resonators are
smaller diameter
mufflers.
They lack the volume of larger
mufflers
but fit in places where a full size muffler will not. Use them
to help
quiet down
a loud system. Different lengths will affect different sound
frequencies. These will help reduce droning on systems with just
a single medium muffler at the rear.
Perforated core resonators do not affect flow at
all. Louvered core resonators will flow about 5% less but do a
better job at silencing things.
|
Perforated Core resonator on the left,
Louvered Core Resonator on the right. |
| Louvered
Core Aluminized Steel |
| Pipe Dia |
Body Dia |
Length |
Part Number |
Price |
| 2.5" |
4" |
12' |
ALLI-RESL-25012 |
$30 |
| 2.5" |
4" |
18" |
ALLI-RESL-25018 |
$36 |
| 2.5" |
4" |
24" |
ALLI-RESL-25024 |
$40 |
| 3" |
4" |
12" |
ALLI-RESL-30012 |
$32 |
| 3" |
4" |
18" |
ALLI-RESL-30018 |
$36 |
| 3" |
4" |
24" |
ALLI-RESL-30024 |
$40 |
| Perforated
Core Stainless Steel |
| Pipe Dia |
Body Dia |
Length |
Part Number |
Price |
| 3" |
4" |
12" |
-RESP-SS-312 |
$60 |
| 3" |
4" |
24" |
-RESP-SS-324 |
$75 |
High Flow Cats
| Large body catalytic converters available in either 2 1/2" or 3" inlet and outlet sizes. Both have the same high flow core. No flanges welded on. Just bare pipes at the ends. EPA OBD2
Legal. They are NOT CARB legal for use in California to pass the newest smog visual test, they do not have the proper labeling for CARB approved use. Overall length is 16" Cat body size is 12" x 6" x
3 1/2" |
| 2.5" High Flow Cat OBD2 Legal - Not CARB Legal |
MAG-93506CA |
$110 |
| 3" High Flow Cat OBD2 Legal - Not CARB Legal |
MAG-93509CA |
$120 |
Flex Sections
|
Braided Covered Flex Section |
| 10" overall length, flex part is 8"
long. Solid ends are aluminized steel. Braided covering and
corrugated inner flex material are stainless steel. Smooth inner braid liner for less inner turbulence. |
| 3" Braided Covered Flex Section |
FLEX-BRAID-300 |
$54.00 ea. |
 |
| 2.5" Braided Covered Flex Section |
FLEX-BRAID-250 |
$49.00 ea. |
|
Stainless Steel Spiral Flex. |
| A nice budget alternative. Smaller
outside diameter for tight spaces. We usually install it so that
there is about 6 to 8" of flex area, and about 2" of overlap
onto the pipe. The overlap makes it easier to weld and gives
good support. The 1 1/2" flex is perfect for external W/G dump
tubes. |
 |
| 1 1/2 " inside diameter |
FLEX-SPI-150 |
$15 per foot |
| 2 1/2" inside diameter |
FLEX-SPI-250 |
$20 per foot |
| 3" inside diameter |
FLEX-SPI-300 |
$25 per foot |
|
Dead Flex Sections
If you are killing flex sections in your down pipe, check
your motor mounts. Flex sections are only designed to deal with
so much movement. If your motor is flopping all over because of
dead motor mounts, you will keep killing the flex section. |
